The ICAN A23 carbon frame is a full carbon frame that thoroughly pursues aerodynamics and achieves further weight reduction, and has a good balance of aerodynamic effect and handling performance. It is an aero road bike frame that combines speed and ease of handling.
The T47 bottom bracket standard combines the benefits of a large threaded bottom bracket with increased durability and easier maintenance, making it ideal for the rigors of gravel riding.
The ICAN A23 carbon frame is constructed from luxurious full carbon fiber , making it lightweight yet durable enough to rival any high-end model.
The seat clamp is embedded in the frame tube, and the aerodynamic design makes it easy to maintain and maintain, and it looks great. In addition, the seat post height can be freely adjusted.
Specification
Type | Aero road bike carbon frame for disc brakes |
Material | Carbon fiber |
Size | 49/52/54/56cm |
Fork | AO23 specify carbon fork |
Headtube | Straight 1 1/2" head tube |
Weight | Frame 1060+-50g Fork 422+-20g |
Bottom bracket | T47-85.5mm |
Tire clearance |
700C*25C-28C |
Brake mount type |
Flat mount Disc brake 140mm |
Dropout | Front 12*100mm thru-axle Rear 12*142mm thru-axle |
Handlebar&stem | Compatible with ICAN handlebar HBA22 |
Every ICAN frame and rim has a useful product life cycle. Each bike, frame and rim will have a unique identification number and warranty card. Complete the provided card and warranty form, and send them to us. Failure to use the provided warranty card will void your warranty. Save your dated receipt for proof of purchase.
Product Group:
Frame and Rim
Applies to all ICAN and Triaero brand bike frame, and FL Max series, AERO Series, and Alpha series rim.
Coverage:
2-year warranty from the date of purchase.
Conditions:
This warranty does not cover:
Tips:Please contact the official support of ICAN at the first time when you find a quality problem. Please do not repair our products privately, otherwise we will not bear any warranty.
The following will void your warranty
More details can be known from "Warranty & Return".
